Material number 204658
Circuit breaker 3pole. In = 10A; Icu = Ics = 1,5kA at AC 400V
| Series | WS SERIES - MCCB |
|---|---|
| Type | NF-C TYPE (ECONOMY CLASS) |
| Rated Current (A) | 10 |
| Current Type | AC |
| Number of Poles | 3 |
| Rated Voltage (V) | 500 |
| Breaking Capacity at 400V (kA) | 1,5 |
| CE | COMPLIANT |
|---|---|
| UL/cUL | NON-COMPLIANT |
| EAC | NON-COMPLIANT |
| Shipping Approvals | LR, ABS |
| Width (mm) | 67,5 |
|---|---|
| Height (mm) | 96 |
| Depth (mm) | 67 |
| Weight (kg) | 0,35 |
| Discontinued (EOL) | 31.03.2022 |
|---|---|
| Last Time Buy (LTB) | 31.12.2021 |
| End of Service (EOS) | 31.12.2028 |
| Successor | 254684 |
| Serial No. on the Box | QR1 |
| Selling Status | Standard |
|---|
| Cardboard (g) | 0 |
|---|---|
| Other paper (g) | 16 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
| REACH Limit Exceeded | NO |
|---|---|
| Dangerous Goods Class | NO |
| Dangerous Goods Identifier | NO |
| WEEE | B2B |
