    720283-MK230/1/25-02

    720283 - MK230/1/25-02

    Material number 720283

    Installation Contactor; 230V AC; 25A; 2NC

    Request for Quote Add to List
    FA-MDRC: MODULAR CONTACTORS
    Series MODULAR DIN RAIL COMPONENTS
    Type MODULAR CONTACTORS
    Rated Current (A) 25
    Rated Voltage (V) 230
    Current Type AC
    No of Auxiliary Contacts NO 0
    No of Auxiliary Contacts NC 2
    Compliant with Standard(s) EN 60947-4-1, EN 61095, IEC 60947-4-1, IEC 61095, VDE 0660
    PRODUCT DIMENSIONS & WEIGHT
    Depth (mm) 85
    Weight (kg) 0,14
    Width (mm) 17,7
    Height (mm) 65
    CONFORMITY
    CE COMPLIANT
    EAC NON-COMPLIANT
    ENVIRONMENTAL
    RoHS Compliance COMPLIANT
    Dangerous Goods Class NO
