Material number 720634
Modular Isolator; 63A; 4-Pole
| Series | MODULAR DIN RAIL COMPONENTS |
|---|---|
| Type | MODULAR ISOLATOR |
| Rated Current (A) | 63 |
| Rated Voltage (V) | 240/415 |
| Number of Poles | 4 |
| Cycles with Rated Current | 3000 |
| Cycles without Rated Current | 16000 |
| Compliant with Standard(s) | EN 45545-2, IEC 61373, IEC/EN 60947-3 |
| Depth (mm) | 60 |
|---|---|
| Weight (kg) | 0,406 |
| Width (mm) | 70,8 |
| Height (mm) | 80 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 0 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Other paper (g) | 46,00 |
| RoHS Compliance | COMPLIANT |
|---|---|
| Dangerous Goods Class | NO |
