Material number 720548
25A; 3-pole MCB; D-curve Icu=25kA
| Series | MODULAR DIN RAIL COMPONENTS |
|---|---|
| Type | HMCB |
| Rated Current (A) | 25 |
| Rated Voltage (V) | 400 |
| Current Type | AC |
| Number of Poles | 3 |
| Instantaneous Tripping | TYPE D |
| Breaking Capacity at 415V (kA) | IEC 60947-2: 25KA |
| Compliant with Standard(s) | EN 45545-2, IEC 61373, IEC/EN 60947-2 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 0 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Other paper (g) | 15,75 |
| RoHS Compliance | COMPLIANT |
|---|---|
| Dangerous Goods Class | NO |
