Material number 411352
RCCB 2P 80A 300MA TYPE AC
| Series | WS-V SERIES - RCCB |
|---|---|
| Type | BVW-T EARTH CIRCUIT BREAKER |
| Rated Current (A) | 80 |
| Rated Voltage (V) | 240 |
| Current Type | AC |
| Number of Poles | 1+N |
| Cycles with Rated Current | 2000 |
| Cycles without Rated Current | 3000 |
| Rated Current Sensibility (mA) | 300 |
| Pulsating Current Sensibility | TYPE AC |
| Compliant with Standard(s) | IEC 61008-1 |
| Depth (mm) | 74 |
|---|---|
| Weight (kg) | 0,22 |
| Width (mm) | 36 |
| Height (mm) | 90 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| RoHS Compliance | COMPLIANT |
|---|---|
| Dangerous Goods Class | NO |
| WEEE | B2C |
| Dangerous Goods Identifier | NO |
