Material number 247621
RCCB; 2poles; Rated Current: 63A; Current Sensitivity: 300MA
| Series | WS-V SERIES - RCCB |
|---|---|
| Type | BV-D EARTH CIRCUIT BREAKER |
| Rated Current (A) | 63 |
| Rated Voltage (V) | 230 |
| Current Type | AC |
| Number of Poles | 1+N |
| Cycles with Rated Current | 8000 |
| Cycles without Rated Current | 8000 |
| Pulsating Current Sensibility | TYPE AC |
| Rated Current Sensibility (mA) | 300 |
| Compliant with Standard(s) | IEC 61008-2-2 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| Width (mm) | 36 |
|---|---|
| Height (mm) | 85 |
| Depth (mm) | 70 |
| Weight (kg) | 0,2 |
| Predecessor | 135190 |
|---|
| Selling Status | Standard |
|---|
| Cardboard (g) | 23,70 |
|---|---|
| Other paper (g) | 0,05 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 0,03 |
| Other plastic (g) | 0,03 |
| Wood (g) | 4,44 |
| Glass (g) | 0 |
| Others (g) | 0 |
| REACH Limit Exceeded | YES |
|---|---|
| REACH Substance CAS Number | 1306-19-0, 7439-92-1 |
| Dangerous Goods Class | NO |
| Dangerous Goods Identifier | NO |
| RoHS Compliance | COMPLIANT |
| WEEE | B2C |
