Material number 719942
1N RCBO; C-curve; 6A; 30mA; Type A
| Series | MODULAR DIN RAIL COMPONENTS |
|---|---|
| Type | RCBO |
| Rated Current (A) | 6 |
| Rated Voltage (V) | 240 |
| Current Type | AC |
| Number of Poles | 1+N |
| Instantaneous Tripping | TYPE C |
| Breaking Capacity at 415V (kA) | IEC/EN 60947-2: 15, IEC/EN 61009: 10 |
| Cycles with Rated Current | 4000 |
| Cycles without Rated Current | 10000 |
| Rated Current Sensibility (mA) | 30 |
| Pulsating Current Sensibility | AC AND PULSATING DC |
| Compliant with Standard(s) | EC/EN 61009, EN 45545-2, IEC 61373, IEC/EN 60479-2 |
| Depth (mm) | 80 |
|---|---|
| Weight (kg) | 0,199 |
| Width (mm) | 35 |
| Height (mm) | 75 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 0 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Other paper (g) | 14,00 |
| RoHS Compliance | COMPLIANT |
|---|---|
| Dangerous Goods Class | NO |
