Material number 720598
20A; 1-pole DC MCB; C-curve; Icu = 10kA IEC947-2; 220V DC
| Series | MODULAR DIN RAIL COMPONENTS |
|---|---|
| Type | DC MCBS |
| Rated Current (A) | 20 |
| Rated Voltage (V) | 250 |
| Current Type | DC |
| Number of Poles | 1 |
| Instantaneous Tripping | TYPE C |
| Breaking Capacity at 415V (kA) | IEC 60947-2: 10KA |
| Compliant with Standard(s) | IEC/EN 60947-2 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 0 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Other paper (g) | 3,83 |
| RoHS Compliance | COMPLIANT |
|---|---|
| Dangerous Goods Class | NO |
