Material number 720175
2-pole; 1N; AFDD B-Curve 10A; 30mA; Type A
| Series | MODULAR DIN RAIL COMPONENTS |
|---|---|
| Type | AFDD |
| Rated Current (A) | 10 |
| Rated Voltage (V) | 230 |
| Current Type | AC |
| Number of Poles | 2 |
| Instantaneous Tripping | TYPE B |
| Breaking Capacity at 415V (kA) | IEC/EN 61009: 10 |
| Cycles with Rated Current | 4000 |
| Cycles without Rated Current | 20000 |
| Rated Current Sensibility (mA) | 30 |
| Pulsating Current Sensibility | AC AND PULSATING DC |
| Compliant with Standard(s) | IEC/EN 61009, IEC/EN 62606 |
| Depth (mm) | 80 |
|---|---|
| Weight (kg) | 0,28 |
| Width (mm) | 52,5 |
| Height (mm) | 73 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 0 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Other paper (g) | 17,75 |
| RoHS Compliance | COMPLIANT |
|---|---|
| Dangerous Goods Class | NO |
