Material number 747979
Inverter; 1.5kW; 400V class; 3.7A; PROFINET; Coated
| Series | FR-D800 SERIES |
|---|---|
| Type | FR-D800 COMPACT INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current SLD (A) | 5 |
| Rated Output Current ND (A) | 3,7 |
| Rated Motor Capacity SLD (kW) | 2,20 |
| Rated Motor Capacity ND (kW) | 1,5 |
| Frequency Range (Hz) | 0,2 TO 590 HZ |
| Control Method | Adv. magnetic flux vector, PM sensorless vector control, V/F control |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 5 |
| Digital Outputs (Transistor) | 1 |
| Digital Outputs (Relay) | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | NO |
| USB | TYPE C |
| Ethernet Port | 1 |
| Built-In Network | PROFINET, CC-Link IE Field Network Basic, CC-Link IE TSN, MODBUS/TCP |
| Protection Class | IP20 |
| CE | COMPLIANT |
|---|
| Width (mm) | 68 |
|---|---|
| Height (mm) | 128 |
| Depth (mm) | 167,5 |
| Weight (kg) | 1,1 |
| Predecessor | 247603 |
|---|
| Selling Status | Standard |
|---|
| Cardboard (g) | 185 |
|---|---|
| Other paper (g) | 0 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 39,4 |
| Other plastic (g) | 2,2 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
| Dangerous Goods Class | NO |
|---|---|
| Dangerous Goods Identifier | NO |
| RoHS Compliance | COMPLIANT |
| WEEE | B2B |
