FR-D720-1.5K
Material number 217403
The Mitsubishi Electric FR-D720-1.5K is a 1.5 kW inverter for three-phase 200–240 V, rated at 7 A. It suits belt conveyors, pumps, fans, small compressors and food processing equipment on 200 V class systems. V/F, general-purpose magnetic flux vector and optimum excitation control are available, with 150 % overload for 60 seconds and 200 % for 0.5 seconds. From 1.5 kW the FR-D720 is fan-cooled, with a quickly replaceable fan, and life diagnosis monitors capacitor deterioration. A built-in brake transistor supports an optional brake resistor. Two safety stop inputs, PID control, analog inputs, a fault relay and RS-485 Modbus RTU are standard, and the unit is IP20 rated. The output frequency range is 0.2–400 Hz.
FA-INVERTER: INVERTER
| Series | FR-D700 SERIES |
|---|---|
| Type | FR-D700 COMPACT INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 7 |
| Rated Motor Capacity ND (kW) | 1,5 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM , MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 5 |
| Digital Outputs (Transistor) | 1 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | NO |
| RS-485 | 1 |
| USB | NO |
| Ethernet Port | NO |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 80 |
| Standby Power Consumption (W) | 5,5-14 |
| Protection Class | IP20 |
PRODUCT DIMENSIONS & WEIGHT
| Depth (mm) | 135,5 |
|---|---|
| Weight (kg) | 1,4 |
| Width (mm) | 108 |
| Height (mm) | 128 |
CONFORMITY
| CE | COMPLIANT |
|---|---|
| EAC | COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
PRODUCT PACKAGING
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 20 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 310 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 10 |
| Wood (g) | 0 |
| Other paper (g) | 0 |
ENVIRONMENTAL
| REACH Limit Exceeded | YES |
|---|---|
| REACH Substance CAS Number | 7439-92-1, 556-67-2, 15571-58-1, 541-02-6, 13560-89-9, 127-19-5, 12060-00-3 |
| RoHS Compliance | COMPLIANT |
| Dangerous Goods Class | NO |
| WEEE | B2B |
| Dangerous Goods Identifier | NO |
Related Products
Frequently Asked Questions
It suits 1.5 kW motors and delivers 7 A rated output current.
It is typically used on belt conveyors, pumps, fans, small compressors and food processing equipment.
Yes, it has a two-channel safety stop function.
