Material number 734040
Servomotor; HK-KN,series; 750W; Torque 2,4 Nm; max. torque 8,4 Nm; Keyway
| Series | MELSERVO-JE |
|---|---|
| Type | HK-KN |
| Power Supply (V) | 200 |
| Rated Capacity (kW) | 0,75 |
| Inertia | LOW INERTIA |
| Rated Torque (Nm) | 2,4 |
| Maximum Torque (Nm) | 8,4 |
| Rated Speed (rpm) | 3000 |
| Maximum Speed (rpm) | 6700 |
| Inertia (kg*cm2) | 1,37 |
| Brake | NO |
| Shaft Type | KEY SHAFT |
| Protection Class | IP67 |
| Current Type | AC |
| Encoder Type | 24-BIT |
| Encoder Resolution (p/rev) | 16777216 |
| CE | COMPLIANT |
|---|
| Width (mm) | 90 |
|---|---|
| Height (mm) | 101,6 |
| Depth (mm) | 132,5 |
| Weight (kg) | 2,2 |
| Serial No. on the Box | QR1 |
|---|
| Selling Status | Standard |
|---|
| Cardboard (g) | 300 |
|---|---|
| Other paper (g) | 36 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 0 |
| Other plastic (g) | 7 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
| REACH Limit Exceeded | NO |
|---|---|
| Dangerous Goods Class | NO |
| Dangerous Goods Identifier | NO |
| RoHS Compliance | COMPLIANT |
| WEEE | B2B |
