Material number 473233
Temperature Input Module; NZ2FT Series; 4 channels; -200 - 850°C; 16 bits
| Series | NZ2FT SERIES |
|---|---|
| Type | TEMPERATURE INPUT |
| Power Supply (V) | 24 |
| Current Type | DC |
| Occupied Stations | 1 |
| Integrated Analogue Inputs | 4 |
| Input Type | RTD |
| Applicable RTD Type | PT500, PT200, PT1000, PT100, NI500, NI200, NI120, NI1000, NI100, CU10, 80Ω, 500Ω, 4KΩ, 40Ω, 300Ω, 2KΩ, 1KΩ, 150Ω |
| Int. Current Consumption (A) | 0,03 |
| Depth (mm) | 76 |
|---|---|
| Weight (kg) | 0,1 |
| Width (mm) | 11,5 |
| Height (mm) | 120 |
| CE | COMPLIANT |
|---|---|
| Shipping Approvals | DNV GL, LR |
| EAC | NON-COMPLIANT |
| UKCA | COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 35 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 10 |
| Wood (g) | 0 |
| Other paper (g) | 14 |
| REACH Limit Exceeded | NO |
|---|---|
| RoHS Compliance | COMPLIANT |
| Dangerous Goods Class | NO |
| WEEE | B2B |
| Dangerous Goods Identifier | NO |
