Material number 236718
PLC CC-Link I/O module; 8 analog outputs; voltage; push-in connector
| Series | CC-LINK |
|---|---|
| Type | REMOTE ANALOG OUTPUT |
| Power Supply (V) | 24 |
| Current Type | DC |
| Occupied Stations | 1 |
| Integrated Analogue Outputs | 8 |
| Output Voltage Range (V) | -10-10; 0-5; 1-5 |
| Wiring | CONNECTOR |
| Int. Current Consumption (A) | 0,15 |
| CE | COMPLIANT |
|---|---|
| UL/cUL | COMPLIANT |
| EAC | NON-COMPLIANT |
| UKCA | COMPLIANT |
| Width (mm) | 41 |
|---|---|
| Height (mm) | 115 |
| Depth (mm) | 67 |
| Weight (kg) | 0,16 |
| Serial No. on the Box | QR1 |
|---|
| Selling Status | Standard |
|---|
| Cardboard (g) | 0 |
|---|---|
| Other paper (g) | 0 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 0 |
| Other plastic (g) | 3 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
| REACH Limit Exceeded | YES |
|---|---|
| REACH Substance CAS Number | 7439-92-1, 80-05-7 |
| Dangerous Goods Class | NO |
| Dangerous Goods Identifier | NO |
| RoHS Compliance | COMPLIANT |
| WEEE | B2B |
