Material number 288437
Motor prot. switch. 5,5kW; Ir=9,0 ~ 13,0A; Icu AC 400V=15kA
| Series | MMP-T SERIES |
|---|---|
| Type | MOTOR CIRCUIT BREAKERS |
| Compliant with Standard(s) | EN 60947-4-1, EN 60947-2, IEC 60947-4-1, GB14048.2, IEC 60947-2 |
| Frame Size | 32 |
| Number of Poles | 3 |
| Rated Current (A) | 13 |
| Rated Voltage (V) | 690 |
| Frequency Range (Hz) | 50/60 |
| Rated Capacity (kW) | 5,5 |
| Heater Designation (A) | 13 |
| Range of Setting Current (A) | 9-13 |
| Breaking Capacity at 415V (kA) | ICU: 15; ICS: 7,5 |
| Electrical Durability (Load) | 100000 OPERATIONS |
| Mech. Durability (at no Load) | 100000 OPERATIONS |
| Wiring | SCREW-CLAMP |
| Automatic Tripping Device | THERMAL-MAGNETIC (ADJUSTABLE) |
| Depth (mm) | 82 |
|---|---|
| Weight (kg) | 0,33 |
| Width (mm) | 45 |
| Height (mm) | 90 |
| CE | COMPLIANT |
|---|---|
| EAC | NON-COMPLIANT |
| UL/cUL | NON-COMPLIANT |
| UKCA | COMPLIANT |
| Aluminum (g) | 0 |
|---|---|
| Others (g) | 0 |
| Styrofoam (g) | 0 |
| Cardboard (g) | 0 |
| Steel (g) | 0 |
| Glass (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Other paper (g) | 53 |
| REACH Limit Exceeded | NO |
|---|---|
| RoHS Compliance | COMPLIANT |
| Dangerous Goods Class | NO |
| WEEE | B2B |
| Dangerous Goods Identifier | NO |
